KAD0207508C2 Automatic Bread Maker SD-253 AUST CONTENTS Page Page 1 Operating Instructions 8 REPLACEMENT PARTS (RSA) 2 TROUBLESHOOTING CHART 9 REPLACEMENT PARTS (AUST) 3 DISASSEMBLY PROCEDURE 10 REPLACEMENT PARTS (NZL) 4 WIRING CONNECTION DIAGRAM 11 PACKAGING (ENG) 5 REPLACEMENT PARTS (ENG).SD-253 1 Operating Instructions.SD-253.SD-253.SD-253.SD-253.SD-253.SD-253 2 TROUBLESHOOTING CHART Note: The causes of unsuccessful baking vary and can be divided roughly into user-side problems and bread maker problems. Most problems are caused by the user. Therefore, it is very important to obtain detailed information from customers regarding their conditions of using the bread maker and to specify whether the problem lies with the user or the bread maker.SD-253 Check point Diagnosis Remedy Connection of the heater terminals Check the connection of the heater terminals. Make a proper connection. (If no problem is found with the connection) Replace the heater.
Resistance of the heater (in normal status) 230V: 96Ω.SD-253 Symptom Cause Remedy The bread rises too much. The amount of sugar is excessive. Reduce the amount of sugar. The amount of yeast is excessive. Reduce the yeast to a proper level. A business-use flour with too much protein has Reduce the amount of yeast.SD-253 3 DISASSEMBLY PROCEDURE 3.1. Remove the dispenser cover assembly and the dispenser assembly from the top lid.
Remove the hinge screw from the back of the body. Lift the top lid and slide it to the left to remove it.SD-253 3.2. Control panel assembly 1.
Remove the two screws labeled F. Parts Name Screw F 2.
Remove the control panel assembly by pressing the side of Control panel Ass’y Fig.4 Fig.5 3.3. Board A assembly 1.
Remove the connectors from the solenoid and the lead wire A unit.SD-253 3.4. Remove a screw from the solenoid. Remove the solenoid holder plate and spring A. Fig.8 Parts Name Screw Solenoid holder plate Spring A Control panel Ass’y Solenoid Ass’y 3.5. Bottom plate Before turning the body upside down, remove the kneading blade, bread pan assembly, measuring spoon, and measuring cup.SD-253 3.6. Power cord 1.
As shown in the figure, turn the body upside down with the power cord stored inside the angel unit to prevent damage to the cord. Fig.10 Parts Name Power cord Body Ass’y 3.7.
Remove the six screws labeled F.SD-253 3.8. Power cord 1. Disconnect the power cord connectors. Push the cord bushing A and push out the power cord B.
Fig.14 Parts Name Power cord Fig.13 Cord bushing Parts Name Angle Angle Cord bushing Power cord 3.9.SD-253 3.10. Ground wire A assembly 1. Remove the screw and the spring washer that secures the ground wire A assembly. Raise the two claws of the ground plate up with the flat- blade screwdriver. Remove the ground plate from the heater terminal.SD-253 3.12. Remove the 'Faston' terminal from the heater. Raise the two claws of the ground plate up with the flat- blade screwdriver.
On the outside of the heater case, detach the three claws that secure heater bobbin B.SD-253 3.13. Remove the three screws that secure the inner lid. Insert a thin flat-blade driver into the space between the top lid and the inner lid (six locations) to move it up and take out the inner lid.SD-253 3.15. Belt, Pulley B, and Connector lower unit 1.
Service Manual Honda
Remove the belt by rotating pulley B. Remove the lock nut and then pulley B and the lock washer. Html how to measure speed. Remove the U-cripe and pull out the connector lower unit.SD-253 3.17. Remove the three screws from the mounting shaft Ass’y to remove it. Remove the packing. Caution: Attach the bread pan to the mounting shaft Ass’y while aligning them with the mark. When replacing the mounting shaft Ass’y, replace the packing and the three screws with new ones.SD-253 3.19.
Location of production code The production code is marked on the bottom plate (bottom side) of the main body. Fig.26 Parts Name Production code Bottom plate.SD-253 4 WIRING CONNECTION DIAGRAM Parts Name Parts Name For Angle 16 Flat cable Heater 17 Connector Kneading motor 18 Sensor (W/Fuse) Ground wire A 19 Wire (Orange) Wire (Yellow/Green) 20 Solenoid Ass’y Lead wire B (white) 21 Yellow line.SD-253 5 REPLACEMENT PARTS (ENG) 5.1. Parts Location (ENG).SD-253 5.2. Replacement Parts List (ENG) Ref. Part Name & Description Remarks Ref. Part Name & Description Remarks ADA39E142-0S Dispenser cover Ass´y Caution ADE01R117-0S Angle Unit Water label & protect Seal rubber tape ADY02E142-W Caution label ADA24E142 Power cord Ass´y.SD-253 6 REPLACEMENT PARTS (GER) 6.1. Parts Location (GER).SD-253 6.2.
Replacement Parts List (GER) Ref. Part Name & Description Remarks Ref. Part Name & Description Remarks ADA39G142-0S Dispenser cover Ass´y Caution ADB10E142 P.C.B.holder label & ADE01R117-0S Angle Unit Water Seal protect rubber tape ADY02G107-W.SD-253 7 REPLACEMENT PARTS (BEL) 7.1. Parts Location (BEL).SD-253 7.2.
